Dây rút Panduit 564mm x 12.7mm Black [PRT6EH-C0]

Dây rút Panduit 564mm x 12.7mm Black [PRT6EH-C0]

45.000 VND
45.000 VND
Sale Sold out

Wire Routing, Management & Protection / Cable Wire Ties Mounts Straps / : Panduit PRT6EH-C0

MÔ TẢ SẢN PHẨM

Panduit PRT6EH-C0 Releasable Lashing Cable Ties have a release tab that permits easy release where changes are anticipated during development, production or servicing in the field. Ideal for heavy duty applications. Extra-Heavy cross section, 22.2” (564mm) length. For Indoor or outdoor use, made of Weather Resistant Nylon 6.6 with high resistance to ultraviolet light, are black in color and come in packages of 100.

_THÔNG SỐ KỸ THUẬT:

Product Type Cable Tie
Color Black
Environment Indoor/Outdoor
Material Weather Resistant Nylon 6.6
Standards Met RoHS, CE Compliant, UL 62275 Compliant (Type 1, 11), UL Recognized (File #E56854), CSA Certified
Resistance Properties UV Resistant
For Use With Hand Install Only
Maximum Bundle Diameter (In.) 6
Minimum Bundle Diameter (In.) 0.5
Maximum Bundle Diameter (mm) 152.4
Minimum Bundle Diameter (mm) 12.7
Minimum Installation Temperature (°C) -20
Sub Brand Pan-Ty®
Minimum Installation Temperature (°F) -4
Maximum Operating Temperature (°C) 85
Minimum Operating Temperature (°C) -60
Maximum Operating Temperature (°F) 185
Minimum Operating Temperature (°F) -76
Minimum Loop Tensile Strength (N) 1.112
Minimum Loop Tensile Strength (lb) 250
Overall Length (In.) 22.2
Overall Length (mm) 564
Body Width (In.) 0.5
Body Width (mm) 12.7
Part Features Release tab permits easy release and re-use where changes are anticipated. Used for heavy duty applications.
