PANDUIT

Dây rút Panduit 150mm x 2.6mm Brown, Translucent [PLT1.5M-C71]

Dây rút Panduit 150mm x 2.6mm Brown, Translucent [PLT1.5M-C71]

67.420 VND
67.420 VND
Sale Sold out

Wire Routing, Management & Protection / Cable Wire Ties Mounts Straps / : Panduit PLT1.5M-C71

MÔ TẢ SẢN PHẨM

Panduit PLT1.5M-C71 Locking Cable Ties are designed for harsh environments where a cable tie material is required to hold up to chemical, high radiation, and/or high operating temperature environments. Non-conductive material that is excellent for high temperature applications up to 500 degrees F (260 degrees C). Flammability rating of V-0 with low smoke and toxicity. Miniature cross section, 5.9” Inches (150 mm) length. Made of PEEK, are translucent brown in color and come in packages of 100.

_THÔNG SỐ KỸ THUẬT:

Product Type Cable Ties
Color Translucent Brown
Environment Indoor
Sub Brand Pan-Ty®
For Use With GTS-E, GS2B-E, PTS, PPTS, STS2
Material PEEK
Resistance Properties Chemical, Radiation and High Heat Resistant
Maximum Bundle Diameter (In.) 1.38
Maximum Bundle Diameter (mm) 35
Maximum Installation Temperature (°F) 32
Maximum Operating Temperature (°C) 260
Maximum Operating Temperature (°F) 500
Minimum Bundle Diameter (In.) 0.06
Minimum Bundle Diameter (mm) 1.5
Minimum Installation Temperature (°C) -20
Minimum Installation Temperature (°F) -4
Minimum Loop Tensile Strength (N) 156
Minimum Loop Tensile Strength (lb) 35
Minimum Operating Temperature (°C) -60
Minimum Operating Temperature (°F) -76
Overall Length (In.) 5.9
Overall Length (mm) 150
Body Width (In.) 0.101
Body Width (mm) 2.6
Body Thickness (In.) 0.048
Body Thickness (mm) 1.2
Standards Met RoHS Compliant
Military Cross Reference Number MS3367-4-16
Part Features One-piece locking wedge for consistent performance and reliability. Low thread force and high loop tensile strength.
