Dây rút Panduit 387mm x 7.62mm Black [PLST4HS25-TL300]

Dây rút Panduit 387mm x 7.62mm Black [PLST4HS25-TL300]

15.890 VND
15.890 VND
Sale Sold out

Wire Routing, Management & Protection / Cable Wire Ties Mounts Straps / : Panduit PLST4HS25-TL300

MÔ TẢ SẢN PHẨM

Panduit PLST4HS25-TL300 Stud Mounted Cable Ties mount to a flat surface and wrap around bundles to form a releasable attachment. Made of Heat Stabilized Weather Resistant Nylon 6.6, they satisfy the needs of high temperature and high resistance to ultraviolet light applications. Light-Heavy cross section, 15.3” (389mm) length. They are black in color and come in packages of 250.

_THÔNG SỐ KỸ THUẬT:

Product Type Cable Ties
Color Black
Environment Indoor/Outdoor
Sub Brand Pan-Ty®
For Use With GTH-E, GS4H-E, GS4EH-E, PTH, STH2, ST3EH
Material Heat Stabilized Weather Resistant Nylon 6.6
Resistance Properties Heat and UV Resistant
Maximum Bundle Diameter (In.) 4
Maximum Bundle Diameter (mm) 101.6
Maximum Installation Temperature (°F) 32
Maximum Operating Temperature (°C) 115
Maximum Operating Temperature (°F) 239
Minimum Bundle Diameter (In.) 0.18
Minimum Bundle Diameter (mm) 4.8
Minimum Installation Temperature (°C) -20
Minimum Installation Temperature (°F) -4
Minimum Loop Tensile Strength (N) 534
Minimum Loop Tensile Strength (lb) 120
Minimum Operating Temperature (°C) -60
Minimum Operating Temperature (°F) -76
Overall Length (In.) 15.3
Overall Length (mm) 389
Body Width (In.) 0.3
Body Width (mm) 7.6
Body Thickness (In.) 0.075
Body Thickness (mm) 1.9
Standards Met UL Recognized (File #E56854), UL 62275 Compliant (Type 1, 11), RoHS Complaint
Part Features Heat stabilized weather resistant integral mount pushes onto a threaded stud and the tie wraps around the bundle.
