PANDUIT

Dây rút Panduit 201mm x 4.83mm Black [PLP2S-M0]

Dây rút Panduit 201mm x 4.83mm Black [PLP2S-M0]

3.810 VND
3.810 VND
Sale Sold out

Wire Routing, Management & Protection / Cable Wire Ties Mounts Straps / : Panduit PLP2S-M0

MÔ TẢ SẢN PHẨM

Panduit PLP2S-M0 Locking Push Mount Ties have an easy-to-use all-in-one wingless design to attach bundles to surfaces in confined spaces. The anchor is pressed into a pre-formed hole and locks in place. Made of Weather Resistant Nylon 6.6 with high resistance to ultraviolet light. Standard cross section, 7.88” (200mm) length. They are black in color and come in packages of 1000.

_THÔNG SỐ KỸ THUẬT:

Product Type Cable Ties
Color Black
Environment Indoor/Outdoor
Sub Brand Pan-Ty®
For Use With GTS-E, GS2B-E, GTH-E, GS4H-E, PTS, PTH, PPTS, STS2, STH2
Material Weather Resistant Nylon 6.6
Resistance Properties UV Resistant
Maximum Bundle Diameter (In.) 1.75
Maximum Bundle Diameter (mm) 44.5
Maximum Installation Temperature (°F) 32
Maximum Operating Temperature (°C) 85
Maximum Operating Temperature (°F) 185
Minimum Bundle Diameter (In.) 0.06
Minimum Bundle Diameter (mm) 1.5
Minimum Installation Temperature (°C) -20
Minimum Installation Temperature (°F) -4
Minimum Loop Tensile Strength (N) 222
Minimum Loop Tensile Strength (lb) 50
Minimum Operating Temperature (°C) -60
Minimum Operating Temperature (°F) -76
Overall Length (In.) 7.9
Overall Length (mm) 200
Body Width (In.) 0.19
Body Width (mm) 4.8
Body Thickness (In.) 0.05
Body Thickness (mm) 1.3
Standards Met UL Recognized (File #E56854), UL 62275 Compliant (Type 1, 11), RoHS Complaint
Part Features Cable tie, mount and fastener in a single part. Used to attach bundles to another surface. Anchor is easily pressed into a preformed hole and locks in place.
