PANDUIT

Dây rút Panduit 257mm x 8.89mm Black [IT965-C0]

Dây rút Panduit 257mm x 8.89mm Black [IT965-C0]

12.920 VND
12.920 VND
Sale Sold out

Wire Routing, Management & Protection / Cable Wire Ties Mounts Straps / : Panduit IT965-C0

MÔ TẢ SẢN PHẨM

Panduit Belt-Ty™ in line locking ties are easy to use thanks to low-profile snag-free heads and a belt-like parallel entry lock. Plus, with weather-resistant Nylon 6.6 material, they're ideal for indoor and outdoor environments and harsh UV light. Light-heavy cross section, 10.1in, Tensile strength: 552, black, 100pc.

_THÔNG SỐ KỸ THUẬT:

Product Type Cable Tie
Color Black
Environment Indoor/Outdoor
Sub Brand Belt-Ty™
For Use With GTH-E, GS4H-E, GS4EH-E, PTH
Material Weather Resistant Nylon 6.6
Resistance Properties UV Resistant
Maximum Bundle Diameter (In.) 2.56
Maximum Bundle Diameter (mm) 65
Maximum Installation Temperature (°C) 0
Maximum Installation Temperature (°F) 32
Maximum Operating Temperature (°C) 85
Maximum Operating Temperature (°F) 185
Minimum Bundle Diameter (In.) 0.33
Minimum Bundle Diameter (mm) 8.4
Minimum Installation Temperature (°C) -20
Minimum Installation Temperature (°F) -4
Minimum Loop Tensile Strength (N) 552
Minimum Loop Tensile Strength (lb) 124
Minimum Operating Temperature (°C) -60
Minimum Operating Temperature (°F) -76
Overall Length (In.) 10.1
Overall Length (mm) 257
Body Width (In.) 0.35
Body Width (mm) 8.9
Body Thickness (In.) 0.065
Body Thickness (mm) 1.7
Standards Met RoHS Complaint
Part Features Parallel-entry tie that threads like a belt (180° entry). 50 pct lower head height than conventional 90° ties. Outside teeth protects cable jacket and wire insulation.
