Wire Routing, Management & Protection / Cable Wire Ties Mounts Straps / : Panduit ILT3S-C

MÔ TẢ SẢN PHẨM

Panduit Belt-Ty™ in line locking ties are easy to use thanks to low-profile snag-free heads and a belt-like parallel entry lock. Plus, with Nylon 6.6 material it's ideal for indoor environments. Standard cross section, 11.5in, Tensile strength: 222, natural, 100pc.

_THÔNG SỐ KỸ THUẬT:

Application General
Product Type Cable Tie
Color Natural
Environment Indoor
Material Nylon 6.6
Standards Met UL 62275 Compliant (Type 2, 21), UL Listed #E56854, UL Recognized #56854
Military Cross Reference Number MS3367-29-9
Maximum Bundle Diameter (In.) 3
Minimum Bundle Diameter (In.) 0.19
Sub Brand Belt-Ty™
Maximum Bundle Diameter (mm) 76.2
Minimum Bundle Diameter (mm) 4.8
Maximum Installation Temperature (°C) 0
Minimum Installation Temperature (°C) -20
Maximum Installation Temperature (°F) 32
Minimum Installation Temperature (°F) -4
Maximum Operating Temperature (°C) 85
Minimum Operating Temperature (°C) -60
Maximum Operating Temperature (°F) 185
Minimum Operating Temperature (°F) -76
Overall Length (In.) 11.5
Overall Length (mm) 292
Body Width (In.) 0.19
Body Width (mm) 4.8
Body Thickness (In.) 0.052
Body Thickness (mm) 1.3
Resistance Properties NA
Minimum Loop Tensile Strength (N) 222
Minimum Loop Tensile Strength (lb) 50
Part Features Parallel-entry cable tie that threads like a belt (180° entry), Low profile head avoids snags and reduces overall bundle size, 35% lower head height than conventional 90° ties
