PANDUIT
Dây rút Panduit 305mm x 12.7mm Maroon [HLTP3I-X12]
Dây rút Panduit 305mm x 12.7mm Maroon [HLTP3I-X12]
Regular price
0 VND
Regular price
Sale price
0 VND
Quantity
Couldn't load pickup availability
Wire Routing, Management & Protection / Cable Wire Ties Mounts Straps / : Panduit HLTP3I-X12
MÔ TẢ SẢN PHẨM
Hook & Loop Cable Tie, UL Listed, Loop Style, 12.0, Intermediate Cross Section. Maroon.
_THÔNG SỐ KỸ THUẬT:
| Product Type | Loop Tie |
| Color | Maroon |
| Environment | Indoor |
| For Use With | Network Cables |
| Material | Nylon |
| Maximum Bundle Diameter (In.) | 3.18 |
| Maximum Bundle Diameter (mm) | 81 |
| Sub Brand | StrongHold™ |
| Maximum Installation Temperature (°C) | 50 |
| Maximum Installation Temperature (°F) | 122 |
| Minimum Installation Temperature (°C) | -17 |
| Minimum Installation Temperature (°F) | 1 |
| Maximum Operating Temperature (°C) | 50 |
| Maximum Operating Temperature (°F) | 122 |
| Minimum Operating Temperature (°C) | -18 |
| Minimum Operating Temperature (°F) | 0 |
| Minimum Loop Tensile Strength (N) | 178 |
| Minimum Loop Tensile Strength (lb) | 40 |
| Screw Size | NA |
| Overall Length (In.) | 12 |
| Overall Length (mm) | 305 |
| Body Width (In.) | 0.5 |
| Body Width (mm) | 12.7 |
| Body Thickness (In.) | 0.1 |
| Body Thickness (mm) | 2.5 |
| Resistance Properties | Flame Resistance |
| Standards Met | RoHS Compliant, UL 94V-2 |
| Application | Bundle High Performance Communication Cabling in Air Handling Spaces |
