PANDUIT

Dây rút Panduit [ERT2M-C20]

Dây rút Panduit [ERT2M-C20]

0 VND
0 VND
Sale Sold out

Wire Routing, Management & Protection / Cable Wire Ties Mounts Straps / : Panduit ERT2M-C20

MÔ TẢ SẢN PHẨM

Panduit Elastomeric Cable Ties are built with a locking head design to increase productivity. Thermoplastic polyurethane bundles and protects network data without over-tensioning. They are not only flexible and elastic, but fully releasable to accommodate frequent moves, adds and changes. And, with weather- and UV-resistance, as well as a 94V-0 flammability rating, you can trust them to reliably last in both indoor and outdoor environments. Miniature cross section, 8.5L (216mm), Tensile Strength: 80, Bundles up to 2.4 (60mm), Black, 100pc.

_THÔNG SỐ KỸ THUẬT:

Product Type Cable Tie
Color Black
Environment Indoor/Outdoor
Sub Brand NA
For Use With GTS-E, GS2B-E, PTS
Material Thermoplastic Poly-Urethane (TPU)
Resistance Properties Heat Resistant
Maximum Bundle Diameter (In.) 2.35
Maximum Bundle Diameter (mm) 59.7
Maximum Installation Temperature (°C) 104
Maximum Installation Temperature (°F) 220
Maximum Operating Temperature (°C) 104
Maximum Operating Temperature (°F) 220
Minimum Bundle Diameter (In.) 0.38
Minimum Bundle Diameter (mm) 9.6
Minimum Installation Temperature (°C) -20
Minimum Installation Temperature (°F) -4
Minimum Loop Tensile Strength (N) 80.06
Minimum Loop Tensile Strength (lb) 18
Minimum Operating Temperature (°C) -57
Minimum Operating Temperature (°F) -71
Overall Length (In.) 8.5
Overall Length (mm) 215.9
Body Width (In.) 0.84
Body Width (mm) 21.4
Body Thickness (In.) 0.09
Body Thickness (mm) 2.3
Standards Met NEBS GR-63-CORE, RoHS Complaint
Part Features Elastic Material, No Sharp Edges
