PANDUIT

Dây rút Panduit 305mm x 4.7mm Red [BT3S-C2]

Dây rút Panduit 305mm x 4.7mm Red [BT3S-C2]

7.840 VND
7.840 VND
Sale Sold out

Wire Routing, Management & Protection / Cable Wire Ties Mounts Straps / : Panduit BT3S-C2

MÔ TẢ SẢN PHẨM

Dome-Top® barb ty cable tie, standard cross section, 12.0 (305mm) length, nylon 6.6, red.

_THÔNG SỐ KỸ THUẬT:

Product Type Cable Tie
Color Red
Environment Indoor
Sub Brand Dome-Top®
For Use With GTS-E, GS2B-E, GTH-E, GS4H-E, STS2, STH2, PTS, PTH
Material Nylon 6.6
Resistance Properties NA
Maximum Bundle Diameter (In.) 3
Maximum Bundle Diameter (mm) 76
Maximum Installation Temperature (°C) 0
Maximum Installation Temperature (°F) 32
Maximum Operating Temperature (°C) 85
Maximum Operating Temperature (°F) 185
Minimum Bundle Diameter (In.) 0.06
Minimum Bundle Diameter (mm) 1.5
Minimum Installation Temperature (°C) -20
Minimum Installation Temperature (°F) -4
Minimum Loop Tensile Strength (N) 222
Minimum Loop Tensile Strength (lb) 50
Minimum Operating Temperature (°C) -60
Minimum Operating Temperature (°F) -76
Overall Length (In.) 12
Overall Length (mm) 305
Body Width (In.) 0.185
Body Width (mm) 4.7
Body Thickness (In.) 0.052
Body Thickness (mm) 1.3
Standards Met UL 62275 (File E56854), CSA-C22.2 No. 62275, 11130200, NRC 10CFR50, QPL-AS23190, CSA Certified, RoHS Complaint
Military Cross Reference Number MS3367-7-2
