PANDUIT

Dây rút Panduit 203mm x 4.7mm Gray [BT2S-M8]

Dây rút Panduit 203mm x 4.7mm Gray [BT2S-M8]

2.620 VND
2.620 VND
Sale Sold out

Wire Routing, Management & Protection / Cable Wire Ties Mounts Straps / : Panduit BT2S-M8

MÔ TẢ SẢN PHẨM

Dome-Top® barb ty cable tie, standard cross section, 8.0 (203mm) length, nylon 6.6, gray.

_THÔNG SỐ KỸ THUẬT:

Product Type Cable Tie
Color Gray
Environment Indoor
Sub Brand Dome-Top®
For Use With GTS-E, GS2B-E, GTH-E, GS4H-E, STS2, STH2, PTS, PTH
Material Nylon 6.6
Resistance Properties NA
Maximum Bundle Diameter (In.) 2
Maximum Bundle Diameter (mm) 51
Maximum Installation Temperature (°C) 0
Maximum Installation Temperature (°F) 32
Maximum Operating Temperature (°C) 85
Maximum Operating Temperature (°F) 185
Minimum Bundle Diameter (In.) 0.06
Minimum Bundle Diameter (mm) 1.5
Minimum Installation Temperature (°C) -20
Minimum Installation Temperature (°F) -4
Minimum Loop Tensile Strength (N) 222
Minimum Loop Tensile Strength (lb) 50
Minimum Operating Temperature (°C) -60
Minimum Operating Temperature (°F) -76
Overall Length (In.) 8
Overall Length (mm) 203
Body Width (In.) 0.185
Body Width (mm) 4.7
Body Thickness (In.) 0.045
Body Thickness (mm) 1.2
Standards Met UL 62275 (File E56854), CSA-C22.2 No. 62275, 11130200, NRC 10CFR50, QPL-AS23190, CSA Certified, RoHS Complaint
Military Cross Reference Number MS3367-1-8
