PANDUIT

Dây rút Panduit 155mm x 2.41mm Natural [BT1.5M-C]

Dây rút Panduit 155mm x 2.41mm Natural [BT1.5M-C]

2.940 VND
2.940 VND
Sale Sold out

Wire Routing, Management & Protection / Cable Wire Ties Mounts Straps / : Panduit BT1.5M-C

MÔ TẢ SẢN PHẨM

Dome-Top® barb ty cable tie, miniature cross section, 6.3 (160mm) length, nylon 6.6, natural, standard package.

_THÔNG SỐ KỸ THUẬT:

Product Type Cable Tie
Color Natural
Environment Indoor
Sub Brand Dome-Top®
For Use With GTS-E, GS2B-E, PTS, PPTS, STS2
Material Nylon 6.6
Resistance Properties NA
Maximum Bundle Diameter (In.) 1.5
Maximum Bundle Diameter (mm) 38
Maximum Installation Temperature (°C) 0
Maximum Installation Temperature (°F) 32
Maximum Operating Temperature (°C) 85
Maximum Operating Temperature (°F) 185
Minimum Bundle Diameter (In.) 0.03
Minimum Bundle Diameter (mm) 0.8
Minimum Installation Temperature (°C) -20
Minimum Installation Temperature (°F) -4
Minimum Loop Tensile Strength (N) 80
Minimum Loop Tensile Strength (lb) 18
Minimum Operating Temperature (°C) -60
Minimum Operating Temperature (°F) -76
Overall Length (In.) 6.3
Overall Length (mm) 160
Body Width (In.) 0.095
Body Width (mm) 2.4
Body Thickness (In.) 0.046
Body Thickness (mm) 1.2
Standards Met UL 62275 (File E56854), CSA-C22.2 No. 62275, 11130200, NRC 10CFR50, QPL-AS23190, CSA Certified, RoHS Complaint
Part Features High strength and low thread force
