PANDUIT

Dây rút Panduit [BT1.5I-M1]

Dây rút Panduit [BT1.5I-M1]

1.660 VND
1.660 VND
Sale Sold out

Wire Routing, Management & Protection / Cable Wire Ties Mounts Straps / : Panduit BT1.5I-M1

MÔ TẢ SẢN PHẨM

Dome-Top® barb ty cable tie, intermediate cross section, 6.1 (155mm) length, nylon 6.6, brown.

_THÔNG SỐ KỸ THUẬT:

Product Type Cable Tie
Color Brown
Environment Indoor
Sub Brand Dome-Top®
For Use With GTS-E, GS2B-E, STS2, PTS
Material Nylon 6.6
Resistance Properties NA
Maximum Bundle Diameter (In.) 1.5
Maximum Bundle Diameter (mm) 38
Maximum Installation Temperature (°C) 0
Maximum Installation Temperature (°F) 32
Maximum Operating Temperature (°C) 85
Maximum Operating Temperature (°F) 185
Minimum Bundle Diameter (In.) 0.03
Minimum Bundle Diameter (mm) 0.8
Minimum Installation Temperature (°C) -20
Minimum Installation Temperature (°F) -4
Minimum Loop Tensile Strength (N) 178
Minimum Loop Tensile Strength (lb) 40
Minimum Operating Temperature (°C) -60
Minimum Operating Temperature (°F) -76
Overall Length (In.) 6.1
Overall Length (mm) 155
Body Width (In.) 0.141
Body Width (mm) 3.6
Body Thickness (In.) 0.041
Body Thickness (mm) 1
Standards Met UL 62275 (File E56854), CSA-C22.2 No. 62275, 11130200, NRC 10CFR50, QPL-AS23190, CSA Certified, RoHS Complaint
Military Cross Reference Number MS3367-5-1
