PANDUIT

Dây rút Panduit [BM4S-C]

Dây rút Panduit [BM4S-C]

13.860 VND
13.860 VND
Sale Sold out

Wire Routing, Management & Protection / Cable Wire Ties Mounts Straps / : Panduit BM4S-C

MÔ TẢ SẢN PHẨM

Dome-Top® barb ty marker tie, wrap, miniature cross section, 15.1 (384mm) length, .50 x 2.13 (12.7 x 54.1mm) marker write-on area, nylon 6.6, natural, standard package.

_THÔNG SỐ KỸ THUẬT:

Product Type Cable Tie
Sub Brand Dome-Top®
Color Natural
Environment Indoor
For Use With Bundles
Marker Type Wrap
Material Nylon 6.6
Maximum Bundle Diameter (In.) 4
Maximum Bundle Diameter (mm) 102
Maximum Installation Temperature (°C) 0
Maximum Installation Temperature (°F) 32
Maximum Operating Temperature (°C) 85
Maximum Operating Temperature (°F) 185
Minimum Bundle Diameter (In.) 0.18
Minimum Bundle Diameter (mm) 4.8
Minimum Installation Temperature (°C) -20
Minimum Installation Temperature (°F) -4
Minimum Loop Tensile Strength (N) 222
Minimum Loop Tensile Strength (lb) 50
Minimum Operating Temperature (°C) -60
Minimum Operating Temperature (°F) -70
Overall Length (In.) 15.1
Overall Length (mm) 384
Body Width (In.) 0.185
Body Width (mm) 4.7
Body Thickness (In.) 0.045
Body Thickness (mm) 1.2
Resistance Properties NA
Standards Met UL 62275 Compliant (Type 1, 11),CE Compliant,RoHS Compliant
Military Cross Reference Number MS3368-2-9A
Application General
