PANDUIT

Dây rút Panduit [BC4S-S10-C]

Dây rút Panduit [BC4S-S10-C]

13.990 VND
13.990 VND
Sale Sold out

Wire Routing, Management & Protection / Cable Wire Ties Mounts Straps / : Panduit BC4S-S10-C

MÔ TẢ SẢN PHẨM

Dome-Top® barb ty clamp tie, standard cross section, #10 (M5) screw, 15.6 (396mm) length, nylon 6.6, natural, standard package.

_THÔNG SỐ KỸ THUẬT:

Application General
Product Type Cable Tie
Color Natural
Environment Indoor
Material Nylon 6.6
Standards Met UL 62275 Compliant (Type 2, 21), UL Listed (File #E56854)
Screw Size #10 (M5)
Maximum Bundle Diameter (In.) 4
Minimum Bundle Diameter (In.) 0.06
Sub Brand Dome-Top®
Maximum Bundle Diameter (mm) 102
Minimum Bundle Diameter (mm) 1.5
Maximum Installation Temperature (°C) 0
Minimum Installation Temperature (°C) -20
Maximum Installation Temperature (°F) 32
Minimum Installation Temperature (°F) -4
Maximum Operating Temperature (°C) 85
Minimum Operating Temperature (°C) -60
Maximum Operating Temperature (°F) 185
Minimum Operating Temperature (°F) -76
Overall Length (In.) 15.6
Overall Length (mm) 396
Body Width (In.) 0.185
Body Width (mm) 4.7
Body Thickness (In.) 0.052
Body Thickness (mm) 1.3
Resistance Properties NA
Minimum Loop Tensile Strength (N) 222
Minimum Loop Tensile Strength (lb) 50
