PANDUIT

Dây rút Panduit [BC4LH-S25-L0]

Dây rút Panduit [BC4LH-S25-L0]

20.470 VND
20.470 VND
Sale Sold out

Wire Routing, Management & Protection / Cable Wire Ties Mounts Straps / : Panduit BC4LH-S25-L0

MÔ TẢ SẢN PHẨM

The BC4LH-S25-L0 Dome-Top® barb ty clamp tie, features a unique patented design with its round smooth edges. Paired with the stainless-steel locking barb, these cable ties provide consistent performance, reliability and infinite adjustability through the entire bundle range. Light-Heavy cross section, 15.5” (394mm) length. Appropriate for Indoor/Outdoor use, made of Weather Resistant Nylon 6.6 with high resistance to ultraviolet light, are black in color and come in packages of 50.

_THÔNG SỐ KỸ THUẬT:

Application Used to secure a cable bundle to another surface such a control panel, wall or ceiling.
Product Type Locking Clamp Ties
Color Black
Environment Indoor/Outdoor
For Use With GTH-E, GS4H-E, GS4EH-E
Material Weather Resistant Nylon 6.6
Standards Met UL Compliant 62275, UL Listed #E56854, UL Recognized #E56854
Screw Size .25 (M6)
Maximum Bundle Diameter (In.) 4
Minimum Bundle Diameter (In.) 0.188
Sub Brand Dome-Top®
Maximum Bundle Diameter (mm) 102
Minimum Bundle Diameter (mm) 4.8
Maximum Installation Temperature (°C) 0
Minimum Installation Temperature (°C) -20
Maximum Installation Temperature (°F) 32
Minimum Installation Temperature (°F) -4
Maximum Operating Temperature (°C) 85
Minimum Operating Temperature (°C) -60
Maximum Operating Temperature (°F) 185
Minimum Operating Temperature (°F) -76
Mounting Hole Diameter (In.) 0.26
Mounting Hole Diameter (mm) 6.6
Mounting Hole Width (In.) 0.52
Mounting Hole Width (mm) 13.2
Overall Length (In.) 15.5
Overall Length (mm) 394
Body Width (In.) 0.275
Body Width (mm) 7
Body Thickness (In.) 0.065
Body Thickness (mm) 1.7
Resistance Properties UV Resistant
Minimum Loop Tensile Strength (N) 534
Minimum Loop Tensile Strength (lb) 120
Part Features Design allows for bundling before or after screwing clamp in place
