PANDUIT

Dây rút Panduit [BC4LH-S25-L]

Dây rút Panduit [BC4LH-S25-L]

15.110 VND
15.110 VND
Sale Sold out

Wire Routing, Management & Protection / Cable Wire Ties Mounts Straps / : Panduit BC4LH-S25-L

MÔ TẢ SẢN PHẨM

Dome-Top® barb ty clamp tie, light-heavy cross section, 1/4 (M6) screw, 15.5 (394mm) length, nylon 6.6, natural, standard package.

_THÔNG SỐ KỸ THUẬT:

Application General
Product Type Cable Tie
Color Natural
Environment Indoor
Material Nylon 6.6
Standards Met UL 62275 Compliant (Type 2, 21), UL Listed (File #E56854)
Screw Size .25 (M6)
Maximum Bundle Diameter (In.) 4
Minimum Bundle Diameter (In.) 0.19
Sub Brand Dome-Top®
Maximum Bundle Diameter (mm) 102
Minimum Bundle Diameter (mm) 4.8
Maximum Installation Temperature (°C) 0
Minimum Installation Temperature (°C) -20
Maximum Installation Temperature (°F) 32
Minimum Installation Temperature (°F) -4
Maximum Operating Temperature (°C) 85
Minimum Operating Temperature (°C) -60
Maximum Operating Temperature (°F) 185
Minimum Operating Temperature (°F) -76
Overall Length (In.) 15.5
Overall Length (mm) 394
Body Width (In.) 0.275
Body Width (mm) 7
Body Thickness (In.) 0.065
Body Thickness (mm) 1.7
Resistance Properties NA
Minimum Loop Tensile Strength (N) 534
Minimum Loop Tensile Strength (lb) 120
