PANDUIT

Dây rút Panduit 203mm x 4.7mm Natural [B3M2S-TL]

Dây rút Panduit 203mm x 4.7mm Natural [B3M2S-TL]

32.390 VND
32.390 VND
Sale Sold out

Wire Routing, Management & Protection / Cable Wire Ties Mounts Straps / : Panduit B3M2S-TL

MÔ TẢ SẢN PHẨM

Dome-Top® barb ty marker tie, wrap, standard cross section, 8.0 (203mm) length, 1.81 x .91 (46.0 x 23.1mm) marker write-on area, nylon 6.6, natural.

_THÔNG SỐ KỸ THUẬT:

Product Type Cable Tie
Sub Brand Dome-Top®
Color Natural
Environment Indoor
For Use With Bundles
Marker Type Wrap
Material Nylon 6.6
Maximum Bundle Diameter (In.) 2
Maximum Bundle Diameter (mm) 51
Maximum Installation Temperature (°C) 0
Maximum Installation Temperature (°F) 32
Maximum Operating Temperature (°C) 85
Maximum Operating Temperature (°F) 185
Minimum Bundle Diameter (In.) 0.37
Minimum Bundle Diameter (mm) 9.5
Minimum Installation Temperature (°C) -20
Minimum Installation Temperature (°F) -4
Minimum Loop Tensile Strength (N) 222
Minimum Loop Tensile Strength (lb) 50
Minimum Operating Temperature (°C) -60
Minimum Operating Temperature (°F) -70
Overall Length (In.) 8
Overall Length (mm) 203
Body Width (In.) 0.185
Body Width (mm) 4.7
Body Thickness (In.) 0.45
Body Thickness (mm) 1.2
Resistance Properties NA
Standards Met UL 62275 Compliant (Type 1, 11),CE Compliant,RoHS Compliant
Military Cross Reference Number MS3368-4-9D
Application General
